1300 Thermocouple K Type S Type

1300 Thermocouple K-Type / S-Type

• 🌡️ Type: K-Type or S-Type (Optional)
• 🔥 Measuring Temperature Range: 0°F to 2372°F (0°C to 1300°C)
• ⚡ Versatile Connectivity:
  • Direct connection to Digital Thermometers via its connector.
  • Connector can be removed for compatibility with Temperature Controllers.

🔧 Key Features:

• 🌡️ High-Temperature Measurement: Capable of measuring extremely high temperatures up to 2372°F (1300°C).
• 🔌 Versatile Use: Compatible with both digital thermometers and temperature controllers, offering flexibility for various applications.
• 💪 Durable Construction: Designed with high-quality materials to withstand extreme heat and ensure long-term reliability.
• 📏 Precise Design: Available in two types (K-Type and S-Type) with specific dimensions and specifications for accurate temperature sensing.

⚙️ Technical Specifications:
K-Type Thermocouple:

• 🌡️ Thermocouple Type: K-Type
• 🔥 Measuring Temperature Range: 0°F to 2372°F (0°C to 1300°C)
• 📏 Total Length: 215mm (8.5 inches)
• 📦 Insulation Length: 162mm (6.3 inches)
• 🔗 Tubing: 6 Pcs x 1″ Ceramic Tubes
• 🔒 Insulator: Two-Hole Insulator

S-Type Thermocouple:

• 🌡️ Thermocouple Type: S-Type
• 🔥 Measuring Temperature Range: 0°F to 2372°F (0°C to 1300°C)
• 📦 Probe Diameter: 8mm
• 📏 Probe Length: 225mm

💡 Main Functionality:

• Provides highly accurate temperature measurement for industrial, scientific, and laboratory applications.
• Ideal for environments requiring the measurement of extremely high temperatures (up to 2372°F / 1300°C).
• Designed for versatility, allowing direct connection to digital thermometers or integration with temperature controllers.

⚙️ Applications:

• Industrial furnaces and kilns.
• Metalworking and heat treatment processes.
• Laboratory research and high-temperature experiments.
• Applications requiring precise and reliable temperature monitoring at extreme temperatures.

📝 Important Notes:

• ⚠️ Type Selection: Choose between K-Type or S-Type based on your specific application requirements.
• 🌡️ Temperature Range: Ensure the thermocouple is used within its specified operating range (0°F to 2372°F / 0°C to 1300°C) to avoid damage or inaccurate readings.
• ⚡ Connector Usage: The connector can be used for direct thermometer connections or removed for compatibility with temperature controllers.
• 📦 Handling: Handle with care to avoid damaging the ceramic tubes and insulators, which are critical for maintaining accuracy and durability.

📦 Package Includes:

• 1x K-Type or S-Type Thermocouple (Based on selection).
