2P DC 1000V Solar Mini Circuit Breaker – HRBD1-63 Series
Product Overview:
The HRBD1-63 Series 2P DC Miniature Circuit Breaker is designed for precise overcurrent and short circuit protection in photovoltaic (PV) systems and DC power distribution networks. Rated for up to 1000V DC and available in multiple current ratings from 6A to 63A, this compact breaker ensures safe operation of solar panel arrays, battery banks, and inverters.
Key Features:
- 🔋 Wide Voltage Support: Rated operating voltage up to 1000V DC
- ⚡ Current Range: Available in 6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A
- 🔧 Protection: Provides overload and short-circuit protection for DC circuits
- 📦 Durability: Mechanical life up to 20,000 cycles, electrical life up to 10,000 cycles
- 📐 Compact Design: 2-pole (2P) construction for space-efficient installation
Technical Specifications:
- Product Type: DC Miniature Circuit Breaker (MCB)
- Model: HRBD1-63 Series
- Number of Poles: 2P
- Rated Operating Voltage: DC 12V ~ 1000V
- Rated Current: 1A ~ 63A (selectable)
- Rated Insulation Voltage: 1200VDC
- Breaking Capacity (lcu): 6kA
- Tripping Curve: Type C
- Mounting: Din Rail
- Standards: IEC compliant
Applications:
- ✔️ Solar Photovoltaic Systems (PV)
- ✔️ Battery Storage and Backup Systems
- ✔️ Off-grid and hybrid solar power setups
- ✔️ DC distribution panels in renewable energy projects
Package Includes:
- ✅ 1 × 2P DC Miniature Circuit Breaker (HRBD1-63)
Note: Ensure the selected current rating matches your system requirements. Designed for professional installation in DC applications only.
