18mm Single Phase Digital Wattmeter – kWh Energy Meter AC 230V 50Hz
Product Overview:
This compact 18mm single-phase 1P 2-wire digital wattmeter is designed to accurately monitor and display electrical energy consumption in kilowatt-hours (kWh). Suitable for residential and commercial applications, it features a digital LCD (or analog) display and supports DIN rail mounting for easy installation. Ideal for power monitoring in narrow electrical enclosures.
Key Features:
- 🔧 Ultra-Compact Width: Only 18mm wide – fits tight spaces on DIN rail.
- 📊 Digital LCD or Analog Display: Clear and easy-to-read energy usage data.
- ⚡ High Accuracy: Class 1 metering standard for precise measurement.
- 🔌 Direct Connection: 5(60)A current rating without the need for CT (Current Transformer).
- ⚙️ DIN Rail Mountable: Standard 35mm rail installation.
Technical Specifications:
| Voltage | 230VAC (170V–250V) |
| Current (Direct) | 5(60)A |
| Maximum Current | 60A |
| Measurement Accuracy | Class 1 |
| Mounting | 35mm DIN Rail |
| Display | Digital LCD / Analog (model dependent) |
| CT Required | No (Direct connection) |
| Width | 18mm |
Applications:
- 🏠 Residential Energy Monitoring
- 🏢 Commercial Power Usage Measurement
- 🧰 Panel Builders & Electrical Installers
