Product Overview:
The TB118N Mechanical Timer Switch is a reliable and efficient solution for automating electrical circuits in homes, offices, and industrial settings. Designed with precision and durability in mind, this timer switch allows for easy scheduling of on/off cycles, ensuring energy efficiency and convenience. With its robust contact capacity and mechanical design, it is ideal for controlling lighting, appliances, motors, and other electrical devices.

Key Features:

• ⚙️ Precise Timing: Monthly time accuracy of ±15 seconds (at 25°C), ensuring consistent and reliable performance.
• ⏰ Flexible Scheduling: Supports up to 48 programmable actions, with a minimum interval of 30 minutes and the smallest time unit set at 15 minutes.
• ⚡ High Contact Capacity:
  • Resistance: 15A
  • Incandescent Lamp: 15A
  • Reactance: 12A
  • Motor Load: 220V AC, 1500W
• 🔄 Single Machine, Single Input: Simplifies wiring and installation with a single input circuit structure.
• 💡 Energy Efficiency: Automatically switches devices on/off according to the programmed schedule, reducing energy waste.
• 📦 Durable Design: Built to withstand frequent use with a robust mechanical construction.

———————–

Technical Specifications:

Functionality and Operation:

• ⏲️ Programmable Timings:
  • Set up to 48 actions per day using the handle-inserted method.
  • Each action can be scheduled in 15-minute increments, with a minimum interval of 30 minutes.
• ⚡ Contact Handling:
  • Handles resistive loads up to 15A, incandescent lamps up to 15A, reactance loads up to 12A, and motor loads up to 220V AC, 1500W.
• 🔄 Automatic On/Off Control: The switch automatically turns connected devices on or off based on the programmed schedule, ensuring seamless operation.
• 🌡️ Temperature Stability: Maintains precise timing accuracy within ±15 seconds per month when operating at 25°C.

Applications:

• 💡 Home Automation: Automate lighting, fans, and other appliances to save energy and improve convenience.
• 🏭 Industrial Use: Control machinery, motors, and equipment with precise on/off schedules.
• 🌱 Agriculture: Automate irrigation systems, greenhouse lighting, or ventilation systems.
• 🌊 Water Management: Schedule pumps and water filtration systems for efficient operation.

Package Includes:

• 1x TB118N Mechanical Timer Switch
• 1x User Manual

Important Notes:

• ⚠️ Operating Voltage: Ensure the device is used within the specified voltage range (220V AC) to avoid damage.
• ⚡ Load Capacity: Do not exceed the maximum load capacities (Resistance: 15A, Reactance: 12A, Motor: 1500W) to prevent overloading the device.
• 🌡️ Environmental Conditions: For optimal performance, operate the timer switch within the recommended temperature range (e.g., 25°C for best timing accuracy).
• 🛡️ Safety Precautions: Always disconnect power before installation or maintenance to prevent electrical hazards.
