- 🛡️ Automatic Voltage & Current Protector Socket
- 📦 Model: HRPS1-16C
- 🔌 Power Supply: 90–300VAC, 50/60Hz
- ⚡ Max Load: 1–16A (Adjustable, Default: 16A)
- 📏 Installation: 35mm DIN Rail
- 💡 Power Consumption: <2W
- 🔁 Mechanical Life: 100,000 times
🔧 Protection Features:
- ⚡ Over-voltage Protection: 100V–300V (Default: 270V)
- ⚠️ Under-voltage Protection: 80V–210V (Default: 170V)
- 🔥 Over-current Protection: 1–16A (Default: 16A)
- ⏱️ Action Time: 0.1–30s (Default: 0.5s)
- 🕒 Recovery Delay: 1–500s (Default: 30s)
- 🔄 Power-on Delay: 1–500s (Default: 10s)
- ♻️ Automatic Recovery
- 🔃 Restore Factory Settings: Hold “DOWN” >12s
- ❗ Fault Inquiry: Hold “UP” >12s
📊 Monitoring & Calibration:
- 🔋 Voltage Display
- 🔌 Current Display
- 🛠️ Voltage Calibration: ±9.5%
- 🛠️ Current Calibration: ±9.5%
- 🔗 Plug Type: EU Standard
